358 Security Mesh Fence
358 Security mesh fence, also called 358 welded mesh fence, which is well-known as Security mesh fence. Perfectly suited to high security applications, like military, airport, prison,warehouse, factory etc.
Anti climb mesh fence is also called 358 fence( 3"×0.5"×8 guage) also known as”prison mesh”or anti-climb fence,is a special fencing panel,we can make in our city, this production offers the best value for performance, durability and appearance,”358"comes from its measurements 3" x 0.5" x 8 gauge which equates to approx.76.2mm x 12.7mm x 4mm in metric. 358 mesh, also known as prison mesh, features small holes and welded seams at each intersection, eliminating foot and finger grip and preventing objects from passing through, making it particularly effective for use with traditional hand cutting tools. It is often specified for use in schools, parks, recreation and entertainment venues as well as retail and commercial developments to provide a high level of physical perimeter protection.
The ultimate security protection solutions you’ve been looking for can be found here. Our protective fences are very safe.
Anti-Climb Fence: Everything You Wanted to Know
358 Security mesh fencing features
1. Anti-Cut & Anti-Climb
The Guardian Fence System protects against both cutting and climbing, with heavy gauge mesh and small mesh openings that resist common cutting tools and hand or foot holds.
2. Modular Design
The Guardian system’s modular design makes installation fast and easy, while also providing for affordable upgrade, maintenance and repair.
3. Long Service Life
High quality galvanized steel and aluminum components provide for a long service life. The Guardian system is also available with a super-durable, Architectural Grade Powder Coating.
358 Mesh Applications
1. Prisons, Military base, Power plants, Oil refineries, Airport terminal
2. Telecommunication & utilities substations, Financial center & Complex
3. Car park, Landscaping, Factories, wire houses and industrial sites
4. Supermarkets and hypermarkets, playgrounds and amusement parks, garden gate
5. Gated communities, apartments and condominiums
358 Security Mesh Specification
Panels Description
Material
Low carbon steel wire(Q195,Q235)
Zinc coating
Normal zinc(40–60g), High zinc(80–600g), Black wire and tube
Wire Diameter
4×4mm, 3×4mm, 5×5mm
Mesh Size
12.7×76.2mm, 25×76.2mm, 50×76.2mm
Folds Number
4(≥2.4m H), 3(≥1.8m H), 5(3m H), Flat panel without fold
Welded Strength
Range 540–690N/㎡
Posts Description
Material
Galvanized tube(40–600g zinc), black tube
Post Type
RHS pipe(60×80mm), SHS pipe(60×60mm,75×75mm), H post(55×100mm), C post(60×80mm), CHS(60mm, 76mm), etc.
Post Thickness
1.5mm, 1.8mm, 2mm, 2.5mm, 3mm, etc.
Post Height
If buried under ground, higher 50cm than panel at least; if with plate, higher 10cm than panel.
Post Cap
Plastic, metal(size and type according to the post)
Surface Treatment: PVC caoting, powder coating, hot-dip galvanized, electro-galvanized, none.
Metal clips and clamps are hot-dip galvanized then powder coating.
Packaging and shipping
358 Security Fence is packaged in plastic film and then stored and shipped on wooden pallets. Each package is securely fastened to the pallet by a special type of tape. We are a supplier of 358 security mesh, welcome to contact us!
